Technical Data - Can Seamers Food Industry
Technical Data F403 / F404-T1 / F404-T2
| F403 | F404-T1 | F404-T2 | |
|---|---|---|---|
| Seaming stations | 3 | 4 | 4 |
| Performance | 40-270 cpm || 2'400-16'200 cph | 50-360 cpm || 3'000-21'600 cph | 50-360 cpm || 3'000-21'600 cph |
| Can height standard | 56-200 mm || 204-714 imp | 56-200 mm || 204-714 imp | 56-200 mm || 204-714 imp |
| Can height special | 28-180 mm | 102-701 imp | 28-180 mm | 102-701 imp | 28-180 mm | 102-701 imp |
| Can height special | 100-250 mm || 315-913 imp | 100-250 mm || 315-913 imp | 100-250 mm || 315-913 imp |
| Can diameter | 50-100 mm || 200-401 imp | 50-100 mm || 200-401 imp | 99-154 mm || 401-603 imp |
| Chain pitch | 190.5 mm || 7.5 in | 152.4 mm || 6 in | 209.5 mm || 8.24 in |
| Motor | 2.2/4 kW || 2.9/5.36 HP | 2.2/4 kW || 2.9/5.36 HP | 2.2/4 kW || 2.9/5.36 HP |
| Compressed air | 4.5-6 bar || 65-87 PSI | 4.5-6 bar || 65-87 PSI | 4.5-6 bar || 65-87 PSI |
| Compressed air consumption | 1 Nm³/h || 35 cu ft/h | 1 Nm³/h | 35 cu ft/h | 1 Nm³/h | 35 cu ft/h |
| Weight | 2'900 kg || 6'400 lbs | 3'000 kg | 7'600 lbs | 3'200 kg | 7'100 lbs |
You can find more information about the Ferrum F403 can seamer by clicking the following links:
You can find more information about the Ferrum F404-T1 can seamer by clicking the following links:
You can find more information about the Ferrum F404-T2 can seamer by clicking the following links:
You can find more information about the individual modular conversions by clicking the following links:
Technical Data F405 / F406
| F405 | F406 | |
|---|---|---|
| Seaming stations | 5 | 6 |
| Performance | 70-500 cpm || 4'200-30'000 cph | 80-600 cpm || 4'800-36'000 cph |
| Can height standard | 56-200 mm || 204-714 imp | 56-200 mm || 204-714 imp |
| Can height special | 28-180 mm | 102-701 imp | 28-180 mm | 102-701 imp |
| Can height special | 100-250 mm || 315-913 imp | 100-250 mm || 315-913 imp |
| Can diameter | 50-99 mm || 200-401 imp | 50-100 mm || 200-401 imp |
| Chain pitch | 152.4/161.9/171.5 mm || 6/6.37/6.75 in | 133.4/142.99 mm || 5.25/5.62 in |
| Motor | 2.2/4 kW || 2.9/5.36 HP | 2.2/4 kW || 2.9/5.36 HP |
| Compressed air | 4.5-6 bar || 65-87 PSI | 4.5-6 bar || 65-87 PSI |
| Compressed air consumption | 1 Nm³/h || 35 cu ft/h | 1 Nm³/h | 35 cu ft/h |
| Weight | 3'300 kg | 7'300 lbs | 3'400 kg | 7'500 lbs |
You can find more information about the Ferrum F405 can seamer by clicking the following links:
You can find more information about the Ferrum F406 can seamer by clicking the following links:
You can find more information about the individual modular conversions by clicking the following links:
Technical Data F408 / F410 / F412
| F408 | F410 | F412 | |
|---|---|---|---|
| Seaming stations | 8 | 10 | 12 |
| Performance | 200-800 cpm || 12'000-48'000 cph | 250-1'000 cpm || 15'000-60'000 cph | 300-1'200 cpm || 18'000-72'000 cph |
| Can height standard | 50-190 mm || 200-707 imp | 50-190 mm || 200-707 imp | 50-190 mm || 200-707 imp |
| Can height special | 28-170 mm | 102-611 imp | 28-170 mm | 102-611 imp | 28-170 mm | 102-611 imp |
| Can height special | 100-250 mm || 315-913 imp | n/a | 100-250 mm || 315-913 imp |
| Can diameter | 50-100 mm || 200-401 imp | 50-99 mm || 200-707 imp | 50-84 mm || 200-307 imp |
| Chain pitch | 152.4/161.9 mm || 6/6.37 in | 123.8/133.4 mm || 4.87/5.25 in | 104.7/114.3 mm || 4.12/4.5 in |
| Motor | 4/11 kW || 5.36/14.75 HP | 4/11 kW || 5.36/14.75 HP | 4/11 kW || 5.36/14.75 HP |
| Compressed air | 4.5-6 bar || 65-87 PSI | 4.5-6 bar || 65-87 PSI | 4.5-6 bar || 65-87 PSI |
| Compressed air consumption | 1 Nm³/h || 35 cu ft/h | 1 Nm³/h | 35 cu ft/h | 1 Nm³/h | 35 cu ft/h |
| Weight | 4'100 kg || 9'000 lbs | 4'300 kg | 9'500 lbs | 4'500 kg | 11'000 lbs |
You can find more information about the Ferrum F408 can seamer by clicking the following links:
You can find more information about the Ferrum F410 can seamer by clicking the following links:
You can find more information about the Ferrum F412 can seamer by clicking the following links:
You can find more information about the individual modular conversions by clicking the following links:
